AMD Radeon RX 460

The Radeon RX 460 is a graphics card by AMD, launched on August 8th, 2016. Built on the 14 nm process, and based on the Baffin graphics processor, in its Baffin PRO variant, the card supports DirectX 12. This ensures that all modern games will run on Radeon RX 460. The Baffin graphics processor is an average sized chip with a die area of 123 mm² and 3,000 million transistors. Unlike the fully unlocked Radeon RX 460 1024SP, which uses the same GPU but has all 1024 shaders enabled, AMD has disabled some shading units on the Radeon RX 460 to reach the product's target shader count. It features 896 shading units, 56 texture mapping units, and 16 ROPs. AMD has paired 2,048 MB GDDR5 memory with the Radeon RX 460, which are connected using a 128-bit memory interface. The GPU is operating at a frequency of 1090 MHz, which can be boosted up to 1200 MHz, memory is running at 1750 MHz (7 Gbps effective). Being a dual-slot card, the AMD Radeon RX 460 does not require any additional power connector, its power draw is rated at 75 W maximum. Display outputs include: 1x DVI, 1x HDMI 2.0b, 1x DisplayPort 1.4a. Radeon RX 460 is connected to the rest of the system using a PCI-Express 3.0 x8 interface. The card measures 170 mm in length, and features a dual-slot cooling solution.
